Ereca Camracer 8k
The Camracer is a complete optical fiber transmission solution for camera connections on Outside Broadcast, Studio and Cinema applications. It is composed of a camera-dockable transmitter, agnostic to any type or brand of Camera and a 1RU basestation receiver. With four 12G-SDI channels, the Camracer 8K can fit any camera from simple ENG to 8K Live sport devices making it suitable for any environment and ideal for rentals. Camracer 8K delivers 140 Watts to the camera. An automatic battery backup will help the remote powering system if more power is needed suddenly. Signals control and Setup is done through internal web server. Most signals are also reported on LED display of each unit. An Oled display gives direct access to optical receiving levels and server IP address. An internal audio mixer allows user to mix between talkback, programs inputs and local audio channels for Eng and Reporter headsets. Camera control channel supports: Ethernet, RS422 Serial, Canon RC-V100 protocol (Enhanced Lanc). Camera synchronization supports: Two composite video signals and one timecode.
Fuji HZK25-1000m Lens
The HZK25-1000mm is a box-type broadcast zoom lens in the dual format, supporting two types of large image sensors. It can be mounted on cameras equipped with the Super 35mm sensor or the even larger sensor equivalent to 35mm full frame. The lens achieves optical performance which exceeds 4K. It also facilitates the use of cinema cameras which is becoming increasingly common in the broadcast industry, offering cinematic visual expressions such as shallow depth-of-field for beautiful bokeh in live coverage of sporting events and music concerts. The new HZK25-1000mm is a broadcast zoom lens that uses optical technology, nurtured over many years, to deliver the world’s highest 40x zoom and the world’s longest focal length of 1000mm. It is designed in the dual format, supporting two types of large sensors. The lens normally works with the Super 35mm sensor, and also supports a sensor equivalent to 35mm full frame by way of activating the built-in expander*4 to expand the image circle by 1.5 times. It offers the added benefit of maintaining the same angle of view in both sensors. On the wide-angle side, the lens provides F2.8 aperture, enabling cinematic visual expressions with shallow depth-of-field and resulting beautiful bokeh. The use of large-diameter aspherical lens and fluorite lens*5 controls various forms of aberration thoroughly to achieve optical performance which exceeds 4K. The lens maintains the operation of broadcast lenses involving zoom demand and focus demand even when mounted on a cinema camera. It can also be used with a variety of existing accessories. Furthermore, the lens features an image-stabilization mechanism based on Fujifilm’s unique “ceramic ball roller” system to accurately compensate for on-set vibrations and wind-induced movements for operation stability.
Canon CJ15 4K Lens
The Canon CJ15ex4.3B 15X UHD 4K Portable Wide-Angle Zoom Lens with 2x Extender is a 15x zoom lens designed for mobile UHD 4K ENG-style production. It has a focal length range of 4.3 to 65mm, creating crisp sharp 4K images with excellent tonal reproduction for capturing fine detail. The built-in 2x extender increases the focal length of the zoom range from 8.3 to 130mm, allowing you to get a close shot of your subject while still keeping your distance. Compact and lightweight, the lens is similar in size to Canon's HD lenses but captures 4K resolution in the 2/3" format. It uses Canon's Air Sphere coating technology, which reduces ghosting and flaring and provides improved HDR imagery. The handgrip servo drive uses 16-bit encoders for extreme precision, and the three lens connectors allow you to interface with virtual systems for using lens data. The lens features servo-controlled zoom, focus, and iris, and the handgrip supports standard ENG functionality.
Fujinon Cabrio 85-300mm PL Lens
Fujinon PL 85-300 Cabrio (ZK3.5x85-SA) features an exclusive detachable servo drive unit, making it suitable for use as a standard PL lens or as an ENG-Style lens. The ZK3.5x85 also features flange focal distance adjustment, macro function, and is LDS (Lens Data System) and /i metadata compatible. Despite the impressive 85-300mm focal range the weight its weight is only 3.0kg including servo motors. Videographers used to shooting video in a typical ENG-style will be very comfortable with the servo. Cinematographers will also be right at home with this lens. With the detachable drive removed, the lens is set to accept industry standard cine motors and matte boxes. Plus, the lens has all the lens data output that appeals to a Cine-style shooter. LDS and /i metadata compatibility is very useful when you want to record the position information of zoom, iris and focus for computer animation and other uses.
